Operating Temperature Range:-20C To +75C
Bulk Cable Weight:30 lbs/1000 ft.
Max. Recommended Pulling Tension:25 lbs.
Min. Bend Radius/Minor Axis:1 in.
Min. Bend/Installation:2.600 in.
NEC/(UL) Specification:CMR, UL444
CEC/C(UL) Specification:CMREU
Directive 2011/65/EU (ROHS II):Yes
EU CE Mark:Yes
EU Directive 2000/53/EC (ELV):Yes
EU Directive 2002/95/EC (RoHS):Yes
EU RoHS Compliance Date (mm/dd/yyyy):01/01/2004
EU Directive 2002/96/EC (WEEE):Yes
EU Directive 2003/11/EC (BFR):Yes
CA Prop 65 (CJ for Wire & Cable):Yes
MII Order #39 (China RoHS):Yes
Other Specification:NEMA WC-63.1 Category 5
Flame Test
UL Flame Test:UL1666 Riser
CSA Flame Test:FT4
Plenum/Non-Plenum
Plenum (Y/N):No
Plenum Number:1624P
