Mechanical
Dimensions 210.4 x 95 x 29 mm (8.3 x 3.7 x 1.1")
Weight 610 g (1.3 lb)
Enclosure material Polycarbonate


Hardware
Total non-blocking throughput 9 Gbps
Switching capacity 18 Gbps
Forwarding rate 13.392 Mpps
Networking interface (8) GbE RJ45 ports
(1) 1G SFP port
Management interface Ethernet In-band
Bluetooth BLE
Power method External AC/DC adapter
Power supply 27V DC, 4.4A power adapter (included)
Supported voltage range 24—28V DC
Max. power consumption 8W (Excluding PoE output)
ESD/EMP protection Air: ± 15kV, contact: ± 8kV
Ambient operating temperature -10 to 50° C (14 to 122° F)
Ambient operating humidity 5 to 95% non-condensing
Certifications CE, FCC, IC


PoE
PoE interface (8) 27V passive PoE: 2-pair (pins 4, 5+/7, 8-) or 4-pair (pins 1, 2, 4, 5+/3, 6, 7, 8-)
Total available PoE 110W
Max. passive PoE wattage per port 30W/27V DC
Passive PoE voltage range 27V DC


LEDs
RJ45 data ports PoE
Speed/link/activity
SFP data ports Link/activity


Software
Management application UISP: Version 1.4.0 and later
NDAA Compliant Yes
