Dimensions 87 x 44 x 29 mm (3.4 x 1.7 x 1.1")
Weight 99 g (3.5 oz)
Output voltage 24V DC @ 0.5A
LAN activity indicator No
Gigabit LAN port Yes
Remote reset capability Yes
Reset button Yes
Rated voltage 100-240V AC @ 50/60Hz
Input current 0.3A @ 120V AC, 0.2A @ 240V AC
Inrush current <30A peak @ 120V AC, <60A peak @ 230V AC
Efficiency 75+%
Output ripple 1% Max.
Switching frequency 50 kHz
Line regulation ≤ 3%
Load regulation ≤ 5%
2-pair powering Pins 4, 5 (+) and pins 7, 8 (-)
4-pair powering -
Storage temperature -30 to 70°C (-22 to 158° F)
Ambient operating temperature 0 to 40° C (32 to 104° F)
Ambient operating humidity 35 to 95% noncondensing
AC connector IEC-320 C6
Data IN / PoE RJ45 shielded socket
Surge protection Difference and common mode
Clamping protection 11V data, 60V power
Max. surge discharge 1500A (8/20 μs) power
Peak pulse current 36A (10/1000 μs) data
Shunt capacitance <5 pF data
Response time <1 ns
Certifications CE, FCC, IC, UL
