Mechanical
Dimensions 224 x 82 x 48 mm (8.8 x 3.2 x 1.9")
Weight 0.4 kg (0.8 lb)
Mounting airFiber X mount (Rocket mount compatible)
GPS Pole Mount (Included)
Weatherproofing IP67*
*After installation of IP67 upgrade kit (included).


Hardware
Networking interface (2) GbE RJ45 ports
Power method Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)
Passive PoE 2-pairs (4, 5+; 7, 8-) or (1, 2+; 3, 6-)
Power supply 24V, 1A gigabit PoE adapter (Included)
Supported voltage range 18—54V DC
Max. power consumption 12W
GPS antenna External, magnetic base
Ambient operating temperature -40 to 55° C (-40 to 131° F)
Certifications CE, FCC, IC
NDAA Compliant Yes


Software
Modes PtP Master/Slave
Max. throughput 1+ Gbps
Max. range* 100+ km
*Throughput and range values may vary depending on the environmental conditions.
Encryption AES-256


RF
Max. TX power* 29 dBm
*Depends on regional regulations.
Frequency accuracy ± 2.5 ppm without GPS Synchronization
± 0.2 ppm with GPS Synchronization
Channel bandwidth 10/20/30/40/50/60/80/100 MHz selectable
Programmable Uplink and Downlink duty cycles


Operating Frequency (MHz)
Worldwide 4800 - 6200 MHz*
*Depends on regional regulations.
US/CA
U-NII-1
U-NII-2A
U-NII-2C
U-NII-3
5150 - 5250 MHz
5250 - 5350 MHz
5470 - 5725 MHz
5725 - 5850 MHz
