Dimensions 650 x 650 x 304 mm (25.6 x 25.6 x 11.97")
Weight 9.8 kg (21.61 lb)
Frequency Range 4.9 - 5.8 GHz
Gain 4.9 GHz: 26 dBi
5 - 5.9 GHz: 30 dBi
HPOL Beamwidth 5° (3 dB)
VPOL Beamwidth 5° (3 dB)
F/B Ratio 34 dB
Max. VSWR 1.4:1
Wind Loading 787 N @ 200 km/h (177 lbf @125 mph)
Wind Survivability 200 km/h (125 mph)
Polarization Dual-Linear
Cross-pol Isolation 35 dB Min.
ETSI Specification EN 302 326 DN2
Mounting Universal Pole Mount, Rocket Bracket, and Weatherproof RF Connectors Included
NDAA Compliant Yes
