Mechanical
Dimensions 420 x 420 x 230 mm (16.5 x 16.5 x 9.1")
Weight 2.2 kg (4.9 lb)
Enclosure material UV-stabilized plastic, powder-coated SPCC
Wind loading 380 N at 200 km/h (85.4 lbf at 125 mph)
Wind survivability 200 km/h (125 mph)
Mounting Pole mount kit (Included)


Hardware
Networking interface (1) GbE RJ45 port
Power method Passive PoE 2-pair (4, 5+; 7, 8 return)
Max. power consumption 8.5W
Supported voltage range 20—27V DC
Power supply 24V, 0.5A gigabit PoE adapter (Included)
ESD/EMP protection Air/contact: ± 24 kV
LEDs (1) Power, (1) LAN, (4) WLAN
Salt fog test IEC 68-2-11 (ASTM B117)
Equivalent: MIL-STD-810 G method 509.5
Vibration test IEC 68-2-6
Temperature shock test IEC 68-2-14
UV test IEC 68-2-5 at 40° C (104° F)
Equivalent: ETS 300 019-1-4
Wind-driven rain test ETS 300 019-1-4
Equivalent: MIL-STD-810 G method 506.5
Ambient operating temperature -40 to 70 C (-40 to 158 F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC, RoHS
NDAA Compliant Yes
System
Gain 25 dBi
Channel sizes PtP Mode: 10/20/30/40/50/60/80 MHz
PtMP Mode: 10/20/30/40 MHz


Operating Frequency (MHz)
Worldwide 5150-5875 MHz
USA
U-NII-1
U-NII-2A
U-NII-2C
U-NII-3
5150-5250 MHz
5250-5350 MHz
5240-5725 MHz
5725-5850 MHz


Management Radio (MHz)
Worldwide 2412 - 2472 MHz
US/CA 2412 - 2462 MHz
